High temperature thermocouple sensors with mantle cable
MB609 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0 - 700 °C
- Sensor element : NiCr-CuNi, Fe-CuNi or NiCr-NiAl
- Connection : 2 wire
- Material sensor pipe : AISI304
- Protection : IP67
MB671 Temperature Sensor long mantle type
Key features
- Max. temperature in air : 1150 °C
- Max. temp. in sulphuric oxidizing atmosphere :1050 °C
- Max. temp. in sulphuric deoxidizing atmosphere :650 °C
- Sensor element : NiCr-NiAl or Pt/13 % RhPt
- Connection : 2 wire
- Material sensor pipe : AISI310S
- Protection : IP56
MB704 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0-700 °C
- Sensor element : NiCr-CuNi, Fe-CuNi or NiCr-NiAl
- Connection : 2 or 2x2 wire
- Material sensor pipe : AISI316
- Protection : IP67
MB720 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0-800 °C
- Sensor element : Fe-CuNi or NiCr-NiAl
- Connection : 2 wire
- Material sensor pipe : AISI316
- Protection : IP56
- Weight : 300 g (MB720SK80)
MB744 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0-800 °C
- Sensor element : Fe-CuNi or NiCr-NiAl
- Connection : 2 or 2x2 wire
- Material sensor pipe : AISI304
- Protection : IP67
MB745 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0-800 °C
- Sensor element : NiCr-CuNi, Fe-CuNi or NiCr-NiAl
- Connection : 2 or 2x2 wire
- Material sensor pipe : AISI316
- Protection : IP67
MB858 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0-800 °C
- Sensor element : Fe-CuNi or NiCr-NiAl
- Connection : 2 or 2x2 wire
- Material sensor pipe : AISI304
- Material mantle cable : AISI316
- Max. temp. comp. cable : 260 °C
- Protection : IP67
MB860 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0 - 800 °C
- Sensor element : Fe-CuNi or NiCr-NiAl
- Connection : 2 or 2x2 wire
- Material sensor pipe : AISI304
- Cable temperature range : -60 - 260 °C
- Protection : IP67
MB886 Temperature Sensor long mantle type
Key features
- Sensor temperature range : 0 - 800 °C
- Sensor element : Fe-CuNi or NiCr-NiAl
- Connection : 2 or 2x2 wire
- Material sensor pipe : AISI304
- Material mantle cable : AISI316
- Cable temperature range : -60 - 260 °C
- Protection : IP67
